| Coupling Size Code | 6 |
|---|---|
| Sleeve Type Code | JEMS |
| Sleeve Construction | One Piece Split |
| Sleeve Material | Thermoplastic Elastomer |
| Coupling Overall Length | 1-7/8 in |
| Torque Capacity | 450 in |
| Maximum RPM | 6000 RPM |
| Coupling Outside Diameter | 3-3/4 in |
| Horsepower @ 100 RPM | 0.71 hp |
| Maximum Angular Misalignment | 0.07 ° |
| Maximum Parallel Misalignment | 0.015 in |
| Operating Temperature Range | -50 to +275 °F |
| Series | S-Flex |
| Manufacturer UPC Number | 697950276717 |
